Surface Fusing System Model MR
Continuous process SURFACE FUSING SYSTEM
Principle
- Feed in the powder as it disperses into hot air flows.
- Melt the particle surface.
- The molten particles are rounded off by the surface tension.
- Cooling air keeps them round.
Features
- Fully continuous surface fusing process.
- Uniform spheronization, encapsulation and stabilization process for fine particles possible.
- Processed in a dispersed state, there are few couples particles.
- Higher product recovery due to lower temperature rise inside the nozzle.
- Simple structure for easy maintenance.
Specifications
| Model |
Comp. air consumption [Nm³/min] |
Hot air temp. [ ℃ ] |
Comp. air supply port diameter [－] |
Heater power [kW] |
Blower power [kW] |
Weight of main unit [kg] |
Hot air volume [m³/min] |
Air flow [m³/min] |
Amount of cooling water [L/min] |
Hot air blower power [kw] |
| MR-10 | 0.4 | ～500 |
Rc1/8×1place Rc1/4×2place |
12 | 11 | 80 | 1.1 | 13 | 15 | 0.75 |
| MR-50 | 2.0 | ～500 |
Rc1/4×1place Rc1/2×2place |
45 | 45 | 750 | 5 | 55 | 75 | 1.8 |
| MR-100 | 4.0 | ～350 | Rc1･1/2×1place | 75 | 75 | 1400 | 8 | 100 | 85 | 3.7 |
Optional Specifications
| 1. |
High temperature processing specifications (Twin heater type) |
Discharges the heat flow of up to 600° |
Application Examples
